COMPOSITE PANEL PRODUCTS
- Interior-installed design preserves exterior appearance and simplifies renovation
- SEAL enhances acoustic, thermal efficiency, and air infiltration
- Slim, durable aluminum frames with high-performance finish options
- Optional between-glass venetian blinds with no exposed cords for daylight or privacy control
- The 1297 SEAL is compatible with monolithic or laminated glazing
- The 1437 SEAL is compatible with insulating glass for improved thermal performance
- Field-accessible designs support cleaning, maintenance, and custodial operation
- Practical, cost-effective solution for retrofit and adaptive reuse
- Thermally improved aluminum framing
- 2″ by 4-1/4″ to 8″ framing profiles
- Allowance for 1/8″ to 1″ glazing or infill panels
- Outside-glazed pressure plate system, available in captured and structural silicone-glazed (SSG) configurations
- Shear-block construction
- Suitable for curved applications
- Optional steel reinforcing and heavy-duty, deep vertical mullions
- Optional silicone-glazed intermediate verticals and horizontals
- Interior retrofit installation preserves exterior appearance and simplifies renovation
- Impact-resistant design drop-tested to 2,000 ft-lb for behavioral health and secure-care safety
- Tamper-resistant hardware for high-risk environments
- SEAL performance upgrade improves sound, energy, air, and light control
- Optional between-glass venetian blinds with no exposed raise / lower cords
- Compatible with polycarbonate or laminated glazing for added protection
- Custodial-access operation for safe cleaning, ventilation and maintenance
- Durable aluminum construction with high-quality finish options
- Available in projected and fixed configurations
- Thermally broken framing and sash with insulating thermal barrier
- AAMA AW110PG
- 2″ aluminum frame depth with 3-3/16″ face width
- Allowance for 1″ monolithic glazing, dual- and triple-glazed IGUs or infill panels
- Accessible operation per AAMA 513
- Optional integral window blinds, subframes, mullions, screens, sills and other hardware
- Factory-fabricated, pre-glazed units with pressure-equalized design
- Mortise-and-tenon aluminum frame construction with mitered and angle-reinforced window corners
- 3-1/4″ frame depth
- Heavy-duty meeting rails
- Accommodates up to 1” glazing
- Can sash design and continuous interlock meeting rails
- Zero Sightline Exterior
- Factory Four-Side Silicone Glazing
- AAMA AW-Class Performance
- Two Structural Depth Options – 3250-Z (3¼”) for standard curtainwall inserts; 4250-Z (4″) for larger openings and higher wind loads.
- Project-Out Awning or Casement Vent Configurations
- Concealed Stainless-Steel Hardware – Four-bar friction hinges and multi-point locking (4250-Z)
- Thermally Broken Aluminum Framing
- Compatible with SSG & Captured Systems – Designed for two- and four-side structural glazed curtainwalls or traditional captured systems.
- Supports High-Rise Performance Requirements
- Interior-Accessible, Low-Maintenance Design
- 3-1/4” frame depth
- OX, XO, XOX, XX configurations
- Accommodates glazing units from 1/8” to 1” depth
- Three sill heights available (low, medium, tall)
- Steel ball bearing rollers over a raised sill track
- 3-1/4” frame depth
- Outside glazed louver design
- Inside glazed panel design
- Optional bird and insect screen
- Thermally improved/broken aluminum framing with optional polyamide pressure plates
- 2-1/2″ by 6″ to 11 1/4″ framing profiles
- Allowance for 1/4″ to 1 5/16″ standard glazing or infill panels
- SSG or tape-glazed options
- Screw-spline construction
- Pivot-and-slide head and jamb anchors
- Roll-over dead load sill anchor
- Optional snap-on perimeter closure and accent covers
- AAMA AW-120 performance
- 2,000 ft-lb simulated human-impact resistance tested to AAMA 501.8
- 4″ thermally broken aluminum frame
- Fixed or side-hinged in-swing casement vents
- Concealed hinges, tamper-resistant locking hardware
- Triple glazed capability supports laminated and polycarbonate glazing
- Interior (access panel glazing) – 7/16” or 9/16” tempered laminated, ½” polycarbonate & 19/32” glass-clad polycarbonate
- Optional between-glass blinds
- Supports compliance with security and design standards required by agencies such as New York State Office of Mental Health (NYS-OMH), , VA, and other regulatory bodies
- AAMA AW40 to AW60 air, water, and structural performance
- 2,000 ft-lb simulated human-impact resistance tested to AAMA 501.8 for behavioral health safety and occupant well-being.
- 4″ and 4-5/16″ thermally broken aluminum frame
- Fixed configuration
- Optional between-glass blinds
- Triple glazed
- Designed for secure, healing environments, the 4000i-DTFX meets or supports compliance with security and design standards required by agencies such as New York State Office of Mental Health (NYS-OMH), VA, and other regulatory bodies
- Thermally improved aluminum framing
- 2 1/2″ by 6″ to 10″ framing profiles
- Allowance for 1/4″ to 1 1/8″ glazing or infill panels
- Outside-glazed pressure plate system, available in captured and structural silicone-glazed (SSG) configurations
- Shear-block construction
- Suitable for curved applications
- Optional steel reinforcing and heavy-duty, deep vertical mullions
- Optional silicone-glazed intermediate verticals and horizontals
