- Thermally improved aluminum framing
- 2″ by 4-1/4″ to 8″ framing profiles
- Allowance for 1/8″ to 1″ glazing or infill panels
- Outside-glazed pressure plate system, available in captured and structural silicone-glazed (SSG) configurations
- Shear-block construction
- Suitable for curved applications
- Optional steel reinforcing and heavy-duty, deep vertical mullions
- Optional silicone-glazed intermediate verticals and horizontals
- Thermally improved/broken aluminum framing with optional polyamide pressure plates
- 2-1/2″ by 6″ to 11 1/4″ framing profiles
- Allowance for 1/4″ to 1 5/16″ standard glazing or infill panels
- SSG or tape-glazed options
- Screw-spline construction
- Pivot-and-slide head and jamb anchors
- Roll-over dead load sill anchor
- Optional snap-on perimeter closure and accent covers
- Thermally improved aluminum framing
- 2 1/2″ by 6″ to 10″ framing profiles
- Allowance for 1/4″ to 1 1/8″ glazing or infill panels
- Outside-glazed pressure plate system, available in captured and structural silicone-glazed (SSG) configurations
- Shear-block construction
- Suitable for curved applications
- Optional steel reinforcing and heavy-duty, deep vertical mullions
- Optional silicone-glazed intermediate verticals and horizontals
- Thermally broken aluminum framing with optional polyamide pressure plates
- 2-1/2″ by 7 1/2″ framing profiles
- Allowance for 1″ standard glazing or infill panels
- Outside-glazed pressure plate system, available in captured and structural silicone-glazed (SSG) configurations
- Polyamide pressure plates available for enhanced thermal performance
- Screw-Spline construction
- Optional steel reinforcing and heavy-duty, deep vertical mullions
- Optional silicone-glazed intermediate verticals and horizontals
- Thermally broken aluminum framing with optional polyamide pressure plates
- 2-1/2″ by 7 1/2″ framing profiles
- Allowance for 1″ standard glazing or infill panels
- Outside-glazed pressure plate system, available in captured and structural silicone-glazed (SSG) configurations
- Polyamide pressure plates available for enhanced thermal performance
- Screw-Spline construction
- Optional steel reinforcing and heavy-duty, deep vertical mullions
- Optional silicone-glazed intermediate verticals and horizontals
- Thermally broken aluminum framing with optional polyamide pressure plates
- 2-1/2″ by 6 1/4″ to 10 1/4″ framing profiles
- Allowance for 1/8″ to 1-1/16″ glazing or infill panels
- Outside-glazed pressure plate system, available in captured and structural silicone-glazed (SSG) configurations
- Polyamide pressure plates available for enhanced thermal performance
- Shear-block construction
- Optional steel reinforcing and heavy-duty, deep vertical mullions
- Optional silicone-glazed intermediate verticals and horizontals
- Thermally broken aluminum framing with dual polyamide strut barriers
- 2-1/2″ by 6″ to 10″ framing profiles, dual glazed
- 2-1/2″ by 6-3/4″ to 10-3/4″ framing profiles, triple glazed
- Allowance for 1″ IGUs, including dual glazing
- Allowance for 1-3/4″ IGUs, including triple glazing
- Outside-glazed pressure plate system
- Aluminum or polyamide pressure plates, enhance thermal performance
- Screw-spline or shear-clip construction
- Optional steel reinforcing and heavy-duty, deep vertical mullions
- Optional captured and structural silicone-glazed (SSG) horizontals and verticals
- Thermally broken aluminum framing with dual polyamide strut barriers
- 2-1/2″ by 7-1/2″ framing profiles
- Allowance for 1″ IGUs, dual glazed only
- Outside-glazed pressure plate system
- Aluminum or polyamide pressure plates, enhance thermal performance
- Screw-spline or shear-clip construction
- Optional steel reinforcing and heavy-duty, deep vertical mullions
- Optional captured and structural silicone-glazed (SSG) horizontals and verticals
- Outside glazed
- Inside glazed
- 2 or 4-sided structural silicone glazed
- Screw spline construction
- Accommodates up to 1” glazing
- Outside glazed
- 2 or 4-sided structural glazed
- Accommodates up to 1-5/16” glazing
- Concealed shear block construction
- Thermal isolator used between exterior and interior extrusions
- Outside glazed
- Inside glazed
- 2 or 4-sided structural glazed
- Slope glazed
- Screw spline construction
- Concealed shear block construction
- Accommodates up to 1-5/16” glazing
- Outside glazed
- Concealed shear block construction
- Accommodates up to 1-1/4” glazing
- Optional corner mullions
- Outside glazed – captured
- 2 or 4-sided structural glazed
- Splice sleeve for hoisting
- Single or multi-span capacity
- Aluminum and fiberglass pressure plate options
- Shear block construction
- Screw spline construction
- Accommodates up to 1-1/16” glazing
- Removable face cover
- 2-1/4″ sightline
- Thermally Broken
- Shear block frame construction
- GSA, DoD & VA requirements
- Screw spline construction
- 2-1/4” sight line
- 4-1/2” frame depth
- Dry glazed system
- Accommodates ¼” and 1” glazing
- Thermally broken aluminum framing with dual polyamide strut barriers
- 2″ by 6″ or 7-3/4″ framing profiles
- Allowance for 1″ to 1-1/8″ glazing or infill panels
- Interior and exterior glazing
- Screw-spline construction
- Optional 3″ sightline head starter accommodates vertical interstory movement
- Inside glazed
- 2-1/4” sight line
- 5” frame depth
- Dry glazed system
- Accommodates ¼” and 1” glazing
- Thermally improved aluminum framing
- 2-1/2″ by 8-1/16″, 8-9/16″, 9-9/16″ or 10-9/16″ framing profiles
- Allowance for 1-5/16″ laminated glazing or IGUs
- Outside-glazed pressure plate system, available in captured and structural silicone-glazed (SSG) configurations\
- Shear-block construction
- Optional captured and SSG horizontals and verticals
- Thermally broken aluminum framing
- 2-1/2″ by 7-3/4″ framing profiles
- Allowance for 5/16″ to 1-1/2″ laminated glazing or IGUs
- Outside-glazed system, available in captured and structural silicone-glazed (SSG) configurations
- Shear-block construction
- Engineered for large glass sizes, tall floor-to-floor heights, and demanding structural wind loads
- Designed to meet or exceed stringent energy performance requirements and resist condensation for high-humidity applications
- Screw-spline construction
- Dual and triple insulating glass compatibility
- System integration flexibility coordinates with storefront, zero sightline vents, and specialty glazing systems
- Ideal for: high-rise residential, hospitality, healthcare, education, government buildings
- 4-3/4″, 6 1/4”, 7 1/4”, 8 1/4” or 10 1/4” frame depths
- 2 1/2” or 3” exterior sight line – Many accent covers available
- Proven pressure-plate system designed for field glazing
- Captured or two-side structural glazed
- Splayed mullions available for segmented radii
- Screw-spline construction
- “F” and “T” perimeter anchors
- Zero sight line vents available
- Available with interior access doors and between-glass blinds
- Exterior sun shades and interior light shelves available
- NFRC and Component Modeling Approach (CMA) listed
- Four-Sided Structural Silicone Glazing (SSG)
- 5-1/4″, 6-3/4”, 7-3/4”, 8-3/4”, or 10-3/4” total system depth (with standard 1” glass)
- All grid framing is interchangeable with standard Wausau SuperWall systems
- No exterior exposed framing
- Field face-sealed
- “F” and “T” perimeter anchors
- Exterior accent trim available
- Zero sightline vent inserts
- Exterior sun shades and interior light shelves available
- Narrow 2-1/2″ mullions maximize daylight opening
- Outside glazed
- 2 or 4-sided structural glazed
- Accommodates up to 1-5/16” glazing
- Concealed shear block construction
- Impact-rated
- Outside glazed
- Inside glazed
- 2 or 4-sided structural glazed
- Slope glazed
- Screw spline construction
- Concealed shear block construction
- Accommodates up to 1-5/16” glazing
- Outside glazed
- 2 structural silicone glazed
- 7” and 8” mullion depth available
- Accommodates up to 2-1/4” glazing
- Screw spline construction
- Outside glazed
- 2 or 4-sided structural glazed
- Accommodates up to 1-5/8” glazing
- Concealed shear block construction
- Thermal isolator used between exterior and interior extrusions
- Outside glazed
- 2 or 4-sided structural glazed
- Accommodates up to 1-5/16” glazing
- Concealed shear block construction
- Thermal isolator used between exterior and interior extrusions
