INT810 Sliding Mall Front

Adding greater opening flexibility to today’s interior commercial spaces, the Tubelite’s INT810 Interior Mall Front Sliding Entrance is engineered to interface easily with a variety of punched opening construction types, Tubelite INT810 Mall Front Sliders can be configured as pocketed, one-way stacked and bi-parting applications depending on project design and egress needs.

The Tubelite INT810 Interior Mall Front Slider allows for several slider configurations. It features:

• 1-3/4″ thick door leaves with  2-1/8″ width (narrow) stiles
• Allowance for 3/16″ to 1-1/16″ glazing infill options (1″ Std.)
• Front and back “blade” style glass stops
• Tie-rod construction for greater modification flexibility
• Offers several head channel and floor track options to accommodate numerous door leaf combinations and flooring conditions
• Tracks and headers allowing leaf combinations of up to 5 leaves one-way stacked configurations and corresponding surface mount/recessed track options available
• Multiple bottom rail heights both single rail and stacked options are available offering heights from 3-1/2″ up to 10″ single rail and 12″ (stacked dual 6″ rail) configurations
• Hardware options such as flush finger pulls, pocket edge pulls, hook bolts, mortise cylinders, and thumbturns are all available for application to the INT810 sliders

Paired with Tubelite interior framing systems the INT810 Mall Front Sliders can delivers a comprehensive solution for fast-track construction and renovation project build outs for retail, office, education and other commercial interior spaces. Specify with recycled content for projects’ sustainable goals and LEED documentation.

For accelerated project schedules, aluminum door extrusions making up the INT810 sliders are stocked in Clear, Dark Bronze and Black anodized finishes. Enhancing interior design and décor, Tubelite INT810 Mall Front Sliders can be finished in a full selection of durable, Tubelite standard architectural paint and anodize colors. Specialty and custom finishes also can be selected.
