• 4′ by 9′ single doors with tie-rod construction
• 2″ by 3 1/2″ vertical stiles and top rail
• 6″ bottom rail with a 10″ option for ADA compliance, other options available
• Optional intermediate horizontal or vertical mid-rails and double doors up to 10′ high with engineering approval
• Allowance for 3/16″ to 1″ glazing or infill panels
Our “blade” style glass stops and built in glass jacks make it easier to align the door with the frame during installation.
Tubelite architectural aluminum entrances use a steel tie rod construction that is both strong and flexible, and backed with a lifetime warranty. This tie rod assembly is as durable as welded corner construction, but also lets you modify, disassemble or resize the doors on site. For maximum strength applications, specify steel-reinforced framing and continuous hinges.
Our entrance systems easily integrate with Tubelite storefront and curtain wall systems. Durable anodized and painted finishes provide long-lasting protection and a wide range of color choices for all Tubelite Entrance systems.
 STILE WIDTH |  DEPTH |  GLASS |  AIR |  CRF |  IMPACT RESISTANCE |  FORCED ENTRY |  ADA COMP. |
|---|---|---|---|---|---|---|---|
| 3 1/2" | 2" | Std. Options: 1/4" (6.35mm) Mono. - 1" (25.4mm) IGU 3/16" (4.8mm), 5/16" (7.9mm) 3/8"(7.9mm), 7/16"(11.1mm) Mono. 1/2" (12.7mm), 9/16" (14.3mm) 5/8"(15.9mm), 3/4"(19.1mm) 7/8"(22.2mm) IGU | 1.0 cfm/ft2 @ 1.57 psf | N/A | TBD | N/A | Yes |
STILE WIDTH | DEPTH | GLASS | AIR | CRF |  U-FACTOR | IMPACT RESISTANCE | FORCED ENTRY | ADA COMP. |
|---|---|---|---|---|---|---|---|---|
| 3 1/2" | 2" | Std. Options: 1/4" (6.35mm) Mono. - 1" (25.4mm) IGU 3/16" (4.8mm), 5/16" (7.9mm) 3/8"(7.9mm), 7/16"(11.1mm) Mono. 1/2" (12.7mm), 9/16" (14.3mm) 5/8"(15.9mm), 3/4"(19.1mm) 7/8"(22.2mm) IGU | 1.0 cfm/ft2 @ 1.57 psf | N/A | CRFf = 27 | TBD | N/A | Yes |
STILE WIDTH | DEPTH | GLASS | AIR |  WATER | CRF | U-FACTOR | IMPACT RISISTANCE | FORCED ENTRY | ADA COMP. |
|---|---|---|---|---|---|---|---|---|---|
| 3 1/2" | 2" | Std. Options: 1/4" (6.35mm) Mono. - 1" (25.4mm) IGU 3/16" (4.8mm), 5/16" (7.9mm) 3/8"(7.9mm), 7/16"(11.1mm) Mono. 1/2" (12.7mm), 9/16" (14.3mm) 5/8"(15.9mm), 3/4"(19.1mm) 7/8"(22.2mm) IGU | 1.0 cfm/ft2 @ 1.57 psf | N/A | N/A | CRFf = 27 | TBD | N/A | Yes |
STILE WIDTH | DEPTH | GLASS | AIR | CRF | U-FACTOR | IMPACT RESISTANCE | ADA COMP. |
|---|---|---|---|---|---|---|---|
| 3 1/2" | 2" | Std. Options: 1/4" (6.35mm) Mono. - 1" (25.4mm) IGU 3/16" (4.8mm), 5/16" (7.9mm) 3/8"(7.9mm), 7/16"(11.1mm) Mono. 1/2" (12.7mm), 9/16" (14.3mm) 5/8"(15.9mm), 3/4"(19.1mm) 7/8"(22.2mm) IGU | 1.0 cfm/ft2 @ 1.57 psf | CRFf = 27 | N/A | TBD | Yes |
